BlazeBot
Robot Arm
Navigation Mode
Laser SLAM navigation
Ground Clearance
Can automatically lift 1.8m
Controls
Intelligent range Worry-free operation
Obstacle Avoidance
Intelligent obstacle avoidance
Flexibility, high and low
Can automatically lift 1.8m. The BlazeBot Robot Arm is designed with an advanced vertical lifting mechanism that enables seamless operation across different heights, making it ideal for warehouses, factories, and logistics centers with varied shelving systems.
Intelligent Obstacle Avoidance
3D cameras + laser radar for active avoidance and safer operation. The multi-sensor fusion system provides real-time environmental perception, enabling the robot to navigate complex environments with confidence and precision while ensuring workplace safety.
Intelligent range Worry-free operation
Low battery auto recharge. The intelligent power management system monitors battery levels in real-time and automatically returns to the charging station when power is low, ensuring continuous operation without manual intervention.
Laser SLAM Navigation
Laser navigation, no coding required, with intelligent robotic chassis. The advanced SLAM (Simultaneous Localization and Mapping) technology enables the robot to create accurate maps of its environment and navigate autonomously without the need for complex setup or programming.
Adaptable to various environments
Flexible obstacle avoidance, can be applied to a variety of environments. From manufacturing floors to warehouses and distribution centers, the BlazeBot adapts to different operational requirements with ease, providing versatile automation solutions.
Autonomous Dispatch System
Achieve unified internal deployment of robots for efficient work. The centralized dispatch system enables coordinated operation of multiple robots, optimizing workflow and maximizing productivity across your entire facility.
Product Parameters
General Specifications
| Model | RML-125-1800 |
| Platform size | Total height 2430mm |
| Weights | Approx. 88kg |
| Charging Power | Single-phase three-wire ~220V±10% 50Hz |
| Operating voltage | DC24V |
| Security protection | With laser scanning obstacle avoidance, vision obstacle avoidance, force sensor, emergency stop and other functions |
| External interface | Network port, USB port, HDMI |
| Working environment | Temperature -10℃~+40℃ Relative humidity ≤85%(25℃) Altitude <4000m |
| Effective lifting distance | Lithium iron phosphate 38.4V/25Ah |
| Lifting Speed | 150mm/s |
Master Module
| GPU | 384 – core NVIDIA Volta™ GPU with 48 Tensor Cores |
| CPU | 6 – core NVIDIA Carmel ARMv8.2 64 – bit CPU |
| Internal storage | 6MB L2 + 4MB L3 8 GB 128 – bit LPDDR4x 59.7GB/s |
| Operating system | Ubuntu 18.04 |
| Number of network ports | 1 |
| Number of USB3.0 ports | 4 |
| Number of USB2.0 ports | 1 |
| Other interfaces | GPIOs, I2C, I2S, SPI, UART |
| Sizes | 90mm×103mm×35mm |
